Frame Press |RP 2000 / T 35

Manual, electro-hydraulic frame press for all applications and size ranges
Both presses are suitable for pressing frame constructions as well as for block gluing. The stable frame and press beam design guarantees perfect pressing of all glue joints even at max. pressing forces of 2,000 kg (RP) or 3,500 kg (T35).
Despite the solid design, operation is extremely simple. Dimension adjustment and conversions are possible without great effort.
The extensive accessory packages make the press a true all-rounder.

download product flyer

Basic configuration

Machine frame in torsion-resistant welded construction, made of thick-walled steel tubes with machined running and guide surfaces
Standard widths RP2000: 3.000, 3.500, 4.000, 4.500, 5.000 mm
Standard widths T35: 3.000, 3.500, 4.000, 4.500, 5.000, 5.500, 6.000 mm
Standard heights: 2.000, 2.300, 2.450, 2.600, 2.750, 3.000 mm
Abutment depth circumferential: 100 mm
Solid continuous abutment on the left with machined, glue-repellent coated contact surface
2 ball-bearing vertical press beams with welded-on guide rail for the press cylinders and fixed welded-on lower abutment for permanent precision,
500 mm bottom spacer for ergonomic placement of smaller components
Double-acting vertical press cylinders height-adjustable in 50 mm increments, 120 mm stroke, self-locking by spring-loaded locking bolt, counterweight for easy height adjustment
Extension rod for large workpiece heights
Press plates coated with glue-repellent plastic
Right-sided, multiple ball bearing mounted carriage, easily adjustable to the workpiece width by means of central locking in 50 mm increments, 2 double-acting horizontal press cylinders with counterweight and clamping screw for stepless and easy adjustment to the workpiece height
Central control panel with sensitive hand lever valves for vertical or horizontal hydraulic circuit, installed on the left, with integrated pressure control valve and main switch
Compact hydraulic unit with pressure relief valve

Technical data frame press RP 2000

Vertical pressing cylinder: ø 50 mm, 400 – 2.400 kg

Horizontal pressing cylinder: ø 40 mm, 250 – 1.600 kg

Installation dimensions:

Length: Working width + 950 mm
Height: Working height + 500 mm (cylinder stroke 120 mm)
Depth: approx. 900 mm

Extra equipment / accessories

Individual working widths or heights, abutment depths
Additional vertical press beams or horizontal press cylinders
Individual pressure control for intermediate vertical and/or horizontal cylinders for pressing of transoms and mullions, etc.
Individual grouping of the press cylinders
Vertical cylinder stroke 200 mm
Small size accessory sets for pressing of small components
Pendulum press plates for inclined components, incl. piston rod guide and press beam locking
Attachable double pendulum press plate for triangle/studio windows
Additional elements for pressing of carcasses and corpuses
Spindle driven or hand-hydraulic side pressure unit, to be hung in
Side pressure unit movable over the entire working length, optional with parking space
Counter block equipment for the pressing of outside profiled frames
Freely movable control panel, electric valves with pushbutton control
Double-sided version
Traversable ladders
Discharge systems

Technical data frame press T35

Vertical pressing cylinder: ø 60 mm, 550 – 3.500 kg

Horizontal pressing cylinder: ø 40 mm, 250 – 1.600 kg

Installation dimensions:

Length: Working width + 1.100 mm
Height: Working height + 500 mm (cylinder stroke 120 mm)
Depth: approx. 1.000 mm

Dimensions and design subject to change without notice.
